Synplicity HAPS-511332 FPGA Prototyping Board

This listing is for a Synplicity HAPS-511332 FPGA-based prototyping board, part of the HAPS (High-performance ASIC Prototyping System) series, ideal for rapid ASIC and SoC prototyping. These platforms provide scalable and high-capacity FPGA resources, enabling pre-silicon verification and system validation.

The board includes numerous high-speed connectors, a central FPGA socket with cooling fan installed, power regulation circuitry, and onboard memory.  It includes standard interfaces and I/O expansion headers for modular integration. This system is widely used in high-speed logic emulation and SoC architecture validation.

Visible Components & Features:

• FPGA socket with cooling fan

• Kingston KVR16LS11/8 8GB SODIMM DDR

• ISS and PLX chips onboard

• USB and power interfaces

• Modular HAPS interconnect headers

• HAPS-511332 Rev C (marked on rear side)

• Synplicity and HAPS branding

• Onboard regulators and status LEDs

• Fully populated with passive and active components
