RS1 1 inch pillar post

Product Description

RS1 Ø1″ Pillar Post (1″ Height, 1/4″-20 Taps)

This compact aluminum pillar post provides rigid support for optical components in space-constrained laboratory and industrial applications.

Key Features:

• Low-Profile Design: 1″ (25.4mm) height for compact setups

• Standard Threading: 1/4″-20 taps on both ends (top/bottom)

• Precision Machined: 6061-T6 aluminum with Type II anodization

• High Stability: ±0.001″ (0.025mm) diameter tolerance

Technical Specifications:

• Material: Aircraft-grade aluminum

• Surface Flatness: <0.0005″ (0.013mm)

• Thread Depth: 0.3″ (7.6mm) per side

• Load Capacity: 15 lbs (6.8kg) vertical

Recommended Pairings:

• PH4 post holder for angular adjustments

• BA1 breadboard adapters

Applications:

• Laser system component mounting

• Optical table experiments

• Industrial sensor positioning

• Microscope stage extensions
