Wideband Systems DRS8300X-3.6TB-2IFXX/RFSB

The Wideband Systems DRS8300X-3.6TB-2IFXX/RFSB is a cutting-edge telemetry data recorder engineered for demanding applications. With an impressive 3.6TB storage capacity and support for high data rates, it provides reliable and efficient telemetry data recording, ideal for industries such as aerospace, defense, and research.

Key Features:

• Model: DRS8300X-3.6TB-2IFXX/RFSB

• Storage Capacity: 3.6TB (with removable disk banks)

• Data Rate: Supports aggregate data rates up to 3,200 Mbps

• Recording Modes: Striped, mirrored, and sequential modes

• Interface Boards: Up to three user-installable Interface Boards (IFBs)

• Timing Interfaces: Compatible with IRIG-A, IRIG-B, IRIG-G, 1PPS, and 10MHz references

• Dimensions: 5.25″ H x 19″ W x 23.5″ D

• Weight: 40 lbs (18.1 kg)

• Power Requirements: 90-132/180-264 VAC, 47-63 Hz, <350 Watts

• Operating Temperature: 5°C to 50°C

• Non-operating Temperature: -25°C to 65°C

• Humidity: 5% to 95% non-condensing

Common Applications:

• Aerospace and defense telemetry testing

• High-speed data recording for missile and satellite tests

• Military and government telemetry applications
