Vicor V28A48M200BL3 DC DC Converter Module

The V28A48M200BL3 is part of Vicor’s Maxi (200 W) isolated DC-DC converter family.

It accepts a 9–36 V input voltage and provides a 48 V output at up to 4.17 A, delivering 200 W of power.

It uses a full-brick through-hole package, measuring approximately 4.60″ × 2.20″ × 0.62″ (116.8 mm × 55.9 mm × 15.7 mm).

Features include isolation, OVP (over-voltage protection), UVLO (under-voltage lockout), and an isolation voltage rating of 3 kV.

Operating temperature ranges from −55 °C to +100 °C, and typical efficiency is around 82.6 %.
