Tektronix TDS 5054B Digital Phosphor Oscilloscope

Tektronix TDS 5054B Digital Phosphor Oscilloscope. 500 MHz. Powers on. No Operating System. Serial no.B021130. No manual, probes, software or other accessories. As shown. Serial no.B021130.

The Tektronix TDS 5054B Digital Phosphor Oscilloscope is a high-performance instrument engineered for advanced signal analysis and troubleshooting in research, development, and production environments. Featuring digital phosphor technology, this oscilloscope delivers superior waveform clarity and persistence, enabling engineers to capture transient events and subtle signal anomalies with exceptional detail.

Key Specifications:

• Bandwidth: 500 MHz
• Channels: 4
• Maximum Sample Rate: Up to 5 GS/s (single channel)
• Memory Depth: Up to 40 Mpts (configurable per channel)
• Display: High-resolution color LCD with digital phosphor persistence
• Triggering: Advanced edge, pulse, and digital triggering with multiple trigger modes
• Connectivity: GPIB, USB, and optional LAN for remote control and data logging
• Vertical Sensitivity: Ranges from 2 mV/div to 5 V/div
• Time Base Range: 200 ps/div to 50 s/div

Features and Benefits:

1. Digital Phosphor Technology:

   • Provides enhanced waveform persistence and brightness, enabling clear visualization of complex, transient, or repetitive signals.

2. High-Speed Performance:

   • A 500 MHz bandwidth and up to 5 GS/s sample rate ensure accurate capture of high-frequency events and fast transient phenomena.

3. Deep Memory & Flexible Acquisition:

   • With up to 40 Mpts memory depth, the TDS 5054B captures long-duration waveforms without sacrificing resolution.

4. Advanced Triggering Capabilities:

   • Multiple triggering modes, including digital and edge triggers, allow precise capture of intermittent and complex signals.

5. User-Friendly Interface:

   • Intuitive front-panel controls and a clear, high-resolution color display facilitate quick setup and detailed analysis.

6. Remote Connectivity:

   • GPIB, USB, and optional LAN interfaces enable seamless integration into automated test systems and remote monitoring environments.

Applications:

• Electronic Design and Debugging:
  • Analyze and debug high-speed digital and analog circuits with precision.
• Research & Development:
  • Conduct detailed signal analysis in academic and industrial R&D labs.
• Production Testing & Quality Control:
  • Ensure consistent performance of electronic components and systems during manufacturing.
• Telecommunications and RF Testing:
  • Capture and analyze complex signal behaviors in communication systems.

What’s Included:

• 1 x Tektronix TDS 5054B Digital Phosphor Oscilloscope
• Power Cord

Why Choose the Tektronix TDS 5054B?

The TDS 5054B combines the proven reliability of Tektronix with advanced digital phosphor technology to deliver unmatched waveform clarity and measurement precision. Its high-speed performance, deep memory, and versatile triggering capabilities make it an essential tool for engineers and researchers requiring accurate and detailed signal analysis in modern electronic applications.
