RF Lambda RFSPSTR0815W50 Coaxial Single Pole Single Throw Switch – LOT OF 3

The RF-Lambda RFSPSTR0815W50 is a reflective coaxial single-pole single-throw (SPST) switch designed for high-performance applications within the 0.8–1.5 GHz frequency range. This switch is suitable for use in wireless infrastructure, test and measurement setups, and military or aerospace systems.

Key Specifications

• Frequency Range: 0.8 to 1.5 GHz

• Insertion Loss: Typically 0.9 dB

• Isolation: 60 to 75 dB

• Input/Output VSWR: 1.3:1 to 1.5:1

• RF Input Power (CW): Up to 50 W

• 0.1 dB Compression Point: 47 dBm

• Third-Order Intercept Point (IIP3): 55 dBm

• Switching Speed: 1 to 1.5 µs

• Bias Voltage: +5 V TTL compatible

• Bias Current: 100 mA

• Connectors: SMA Female

• Weight: 1.76 ounces

• Material: Gold-plated aluminum

Application Areas

• Wireless Infrastructure: Ideal for base stations and communication networks.

• Test and Measurement: Suitable for RF testing environments.

• Military and Aerospace: Meets stringent requirements for defense applications.
