RF Amplifiers TriQuint

Tri Quiny RF Amplifiers

RF Amplifier 50-1500MHz 1W 5V P1dB 30dBm @ 940MHz

Attribute	Attribute Value
Manufacturer	TriQuint (Qorvo)
Product Category	RF Amplifiers
Series	TQP
Type	High Linearity Amplifier
Packaging	Reel
Unit-Weight	0.004603 oz
Mounting-Style	SMD/SMT
Gain	19.5 dB
Test-Frequency	940 MHz
Maximum Operating Temperature	+ 85 C
Operating-Supply-Voltage	5 V
Operating-Supply-Current	220 mA
Operating-Frequency	50 MHz to 1.5 GHz
NF-Noise-Figure	6.3 dB
P1dB-Compression-Point	30 dBm
Part-#-Aliases	1083222
Package-Case	SOT-89-3
OIP3-Third-Order-Intercept	47 dBm
Manufacturer	Qorvo
Product-Category	RF Amplifier
RoHS	Details
P1dB-Compression-Point	30 dBm
Maximum-Operating-Temperature	+ 85 C
Brand	TriQuint (Qorvo)
