Radiall 7002-1541-010 SMA jack – lot of 17

Product Description

Radiall USA, Inc. 7002-1541-010 SMA Female Jack Connector (50 Ohm, Bulkhead/Panel Mount)

This is a Radiall 7002-1541-010, a high-performance SMA female jack connector designed for bulkhead or panel mounting in RF/microwave enclosures, test equipment, and communication devices. Engineered to maintain precise 50-ohm impedance, this connector provides a reliable interface for coaxial cable connections in demanding applications from DC to 18 GHz.

Key Specifications:

• Series: SMA (SubMiniature version A)

• Impedance: 50 Ohm

• Gender & Type: Female Jack (socket contact)

• Mounting: Bulkhead/Panel Mount (requires mounting hole; includes hex nut)

• Coupling: Threaded (mating interface: 1/4″-36 UNS-2A thread)

• Contact Termination: Solder cup for center conductor; solder tabs or ground plane connection for panel grounding

• Dielectric: PTFE (Teflon)

• Body Material: Brass, gold-plated finish

• Frequency Range: DC to 18 GHz (standard SMA performance)

• Compliance: Meets MIL-STD-348 and other industry standards

Why This Connector Is a Professional Choice:

• Radiall Quality: Radiall is a globally recognized leader in precision RF connectors, ensuring reliability and performance.

• Secure Mounting: Bulkhead design provides a stable, grounded interface for chassis or panel integration.

• Broad Compatibility: Standard SMA interface mates with SMA plugs, adapters, and cables.

Applications:

• Test & Measurement Equipment: Panel interfaces for signal generators, spectrum analyzers, and vector network analyzers.

• RF Enclosures & Shields: Bulkhead feedthrough for filters, amplifiers, or modular RF systems.

• Telecommunications: Antenna ports, base station modules, and RF subsystem interconnects.

• Aerospace & Defense: Radar, avionics, and secure communication device packaging.
