Pfeiffer Duo 2.5 Rotary Vane Pump

Pfeiffer Vacuum Duo 2.5 Rotary Vane Pump – Compact Two-Stage Vacuum Pump

The Pfeiffer Duo 2.5 is a compact two-stage rotary vane pump designed for reliable and quiet operation in laboratory and industrial environments. Known for its performance and durability, it delivers stable vacuum performance for a wide range of scientific and technical applications.

Key Features:

• Model: Duo 2.5

• Manufacturer: Pfeiffer Vacuum

• Pump Type: Two-stage rotary vane

• Pumping Speed: 2.4 m³/h (at 50 Hz)

• Ultimate Pressure: ≤ 1 x 10⁻³ mbar

• Motor Power: Approx. 0.25 kW

• Inlet/Outlet Connections: DN 16 KF flange

• Cooling Method: Air-cooled

• Oil Type: Recommended Pfeiffer P3 or equivalent vacuum oil

• Noise Level: Low operational noise, ideal for lab use

• Dimensions: Compact footprint for benchtop or system integration

• Weight: Approximately 11.5 kg

Common Applications:

• Laboratory vacuum systems

• Mass spectrometry

• Leak detection setups

• Thin film deposition

• General research and industrial vacuum processes
