MT16KTF1G64AZ-1G6E1 8GB

Product Description

Micron 8GB DDR3L Low-Voltage SODIMM – Laptop/Embedded Memory

This Micron MT16KTF1G64AZ-1G6E1 is an 8GB DDR3L memory module in the small outline dual in-line memory module (SODIMM) form factor. Featuring 1.35V low-voltage (DDR3L) operation and 1600MHz speed, it is designed for upgrading laptops, mini-PCs, industrial embedded systems, and networking equipment from the 2012-2018 era.

Key Specifications:

• Capacity: 8GB

• Type: DDR3L SDRAM (Non-ECC, Unbuffered)

• Speed: 1600 MHz (PC3L-12800S)

• Voltage: 1.35V (Low Voltage – DDR3L)

• Module Type: 204-pin Small Outline DIMM (SODIMM)

• Organization: Likely 1Rx8 or 2Rx8 (standard for 8GB)

• Part Number: MT16KTF1G64AZ-1G6E1

Compatibility & Applications:

• Target Systems: Compatible with a wide range of laptops, all-in-one PCs, Intel NUC mini-PCs, and industrial single-board computers that use DDR3L SODIMMs and support 8GB modules. Common in systems with Intel 3rd to 6th Gen Core (Ivy Bridge to Skylake) mobile processors.

• Primary Use:

  1. Laptop/Mini-PC Upgrade: Cost-effective RAM increase for older portable and compact systems.

  2. Embedded/Industrial Maintenance: Reliable replacement for failed modules in kiosks, digital signage, or networking hardware.
