LightPath 355397C Aspheric Lens – LOT OF 25

The LightPath 355397C Aspheric Lens Substrate is a high-performance optical component designed for precision applications. Featuring a 7.2mm diameter and a numerical aperture (NA) of 0.30, this lens ensures excellent light transmission and focal quality. The D-ZLAF52LA substrate material, combined with a C coating, delivers a durable and reliable solution for a wide range of optical systems.

This lens is equipped with a broadband antireflection (BBAR) coating, specifically optimized for wavelengths in the 600-1050nm range. The BBAR coating reduces surface reflections and enhances light throughput, making it ideal for applications requiring high efficiency and minimal signal loss. The aspheric design helps minimize spherical aberrations, ensuring superior image quality and precision in both imaging and laser systems.

Key Features:

• Diameter: 7.2mm
• Numerical Aperture (NA): 0.30
• Coating: C coating with BBAR (600-1050nm)
• Material: D-ZLAF52LA substrate
• Wavelength Range: 600-1050nm
• Application: Ideal for optical systems requiring high precision and low light loss.

Applications:

• Optical systems requiring high light transmission efficiency
• Laser beam shaping and collimation
• Imaging systems where high-quality focus and minimal aberrations are critical
• Research and development in optical sciences and photonics
