LAPIS Semiconductor OD9245N-MS-LCY

Product Overview
The LAPIS Semiconductor OD9245N-MS-LCY is a high-speed, surface-mount receiver module designed for optical communication systems operating at data rates up to 10 Gbps. Integrating an InGaAs PIN photodiode with a low-noise transimpedance amplifier (TIA), this module ensures efficient and reliable signal conversion, making it ideal for applications in fiber-optic networks, including OC-192 and STM-64 systems.

Key Specifications

• Data Rate: Up to 10 Gbps
• Wavelength Range: 1250 nm to 1620 nm
• Optical Sensitivity: -18 dBm at 10 Gbps
• Power Consumption: Typically 180 mW
• Operating Temperature Range: -5°C to +85°C

Key Features

• High-Speed Performance: Supports data rates up to 10 Gbps, suitable for high-bandwidth applications.
• Integrated Design: Combines a PIN photodiode with a TIA in a compact, hermetically sealed package, enhancing reliability.
• Wide Wavelength Range: Operates effectively across a broad spectrum, accommodating various fiber-optic communication requirements.
• Low Power Consumption: Designed for energy efficiency, reducing operational costs.
• Surface-Mount Package: Facilitates easy integration into existing PCB designs, streamlining the manufacturing process.

Conclusion
The LAPIS Semiconductor OD9245N-MS-LCY receiver module offers exceptional performance for high-speed optical communication systems. Its integrated design, broad wavelength compatibility, and low power consumption make it a valuable component for engineers and researchers developing advanced fiber-optic networks.
