The CYBT-483039-EVAL is a development/evaluation kit built around the CYBT-483039-02 EZ-BT™ WICED® wireless module. It is designed for rapid prototyping of Bluetooth Smart / dual-mode BR/EDR + BLE applications, and is ideal for engineers developing IoT, industrial wireless, or embedded connectivity systems.
Key Features
-
Built-in EZ-BT™ WICED module (CYBT-483039-02) – fully integrated, pre-certified module including crystal oscillators, PA/LNA, chip antenna, etc.
-
Bluetooth dual-mode support: BR/EDR + BLE (Bluetooth 5.0 compliant) with support for LE 2 Mbps, feature set for Bluetooth Smart Ready usage.
-
Industrial temperature range: –30 °C to +85 °C.
-
RF output power: up to +20 dBm (for FCC/ISED certification) allowing extended range line-of-sight wireless communication.
-
Up to 15 general-purpose I/O ports (GPIO) exposed for application interfacing.
-
On-board headers for Arduino-compatible shields (J3/J4/J6/J7) for rapid expansion and prototyping.
-
USB interface for connection to PC/host, simplifying power and communication during development.
| Weight | 2 lbs |
|---|---|
| Dimensions | 8 × 6 × 4 in |
