The Z270-WS LGA1151 ATX Motherboard from Asus is designed for professionals dealing with designing, modeling, rendering, and processing-intensive applications. It’s built on the Intel Z270 chipset with an LGA 1151 socket for 6th and 7th generation Core i7, i5, i3, and Pentium processors. There are four memory slots that support up to 64GB of 3866 MHz overclocked DDR4 RAM, six SATA III ports, two M.2 slots, and two U.2 ports. Using an appropriate drive, you can get speeds of up to 32 Gb/s using the M.2 and U.2 interfaces. While it’s equipped with HDMI and DisplayPort outputs, this motherboard has four PCIe 3.0 x16 slots for graphics cards and a single PCIe x4 slot for other PCIe-based hardware. Other notable features include dual Intel Gigabit LAN and Realtek ALC S1220A 8-channel HD audio.
With one click, Asus 5-Way Optimization dynamically optimizes essential aspects of the system, providing overclocking and cooling profiles that are tailored for performance.
- TurboV Processing Unit (TPU) – Offers the ability to fine-tune voltages, monitor system stats, and adjust overclock parameters for optimal performance
- EPU – Automatically optimizes power consumption and maximizes savings with Away mode
- Fan Xpert 4 – Grants comprehensive control over fans and all-in-one (AIO) liquid coolers
- Digi+ – Delivers real-time control over voltage droop, switching frequency, and power-efficiency settings, allowing you to fine-tune CPU voltage regulation
- Turbo App – Allows you to define CPU overclocking, apply fan profiles, prioritize network data and optimize audio settings
This motherboard is built with the Realtek S1220A audio codec to deliver a clear and immersive listening experience. Asus Crystal Sound 3 incorporates multiple hardware enhancements for better audio. Moreover, DTS Headphone:X offers virtual 3D surround-sound for all types of headphones.
- Power Pre-Regulator – Reduces power-input noise for consistent performance
- Audio Shielding – Prevents multi-lateral interference for clear audio
- Separate Audio Tracks – Left and right tracks are built on different layers of PCB for consistent, equal quality
- De-Pop Circuit – Reduces start-up popping noise to all audio outputs
- Audio Amplifier – Provides high-quality sound for headphones and speakers
- EMI Protection – Prevents electrical noise from interfering with audio quality
- Premium Audio Capacitors – Helps to provide warm, natural, and clear sound
- Macro and keyboard shortcut support with an onboard microprocessor
- Asus metal-reinforced PCIe SafeSlot
- Asus Q-DIMM, Q-Slot, Q-Connector, Q-Shield, Q-LED, and Q-Code
