Analog Devices EV1HMC253ALC4 Evaluation Board

This evaluation board is designed for prototyping and testing the HMC253ALC4 SP4T RF switch, ideal for high-frequency signal routing in communication and test systems.

Key Specifications:

• IC Evaluated: HMC253ALC4 (GaAs SP4T RF switch)

• Frequency Range: DC – 3 GHz

• Insertion Loss: 0.8 dB @ 1 GHz

• Isolation: 40 dB @ 1 GHz

• Control: SPI interface

• Power Supply: +3.3V to +5V

Condition:

⚠ SOLD AS IS
⚠ UNTESTED
⚠ NO POWER SUPPLY OR CABLES INCLUDED
⚠ PULLED FROM DEVELOPMENT ENVIRONMENT

Applications:

• Wireless infrastructure (4G/5G)

• Test and measurement equipment

• Aerospace and defense systems

• RF signal routing
