Analog Devices EV-ADF4159EB3Z evaluation board

Product Description

Analog Devices EV-ADF4159EB3Z Evaluation Board

This as-is evaluation board enables rapid prototyping with the ADF4159 13GHz fractional-N PLL frequency synthesizer.

Key Features:

• Chipset: ADF4159 (6.8-13GHz)

• Interface: SPI control

• Power: 3.3V (verify requirements)

• Compatibility: ADIsimPLL software

Condition:

SOLD AS IS
UNTESTED
NO USB CABLE/SOFTWARE INCLUDED
PICTURE MAY NOT MATCH PRODUCT

Development Applications:

• Radar systems

• Microwave test equipment

• Satellite comms

• Frequency synthesizers
