Analog Devices 9172 evaluation board

Product Description

Analog Devices 9172 Power Management Evaluation Board

This is an evaluation platform for an Analog Devices (ADI) 9172 series power management integrated circuit. The board is designed for engineers to test, characterize, and prototype with ADI’s high-performance multi-phase PWM controllers or voltage regulators, commonly used in computing, telecom, and high-current applications.

Key Details:

• Purpose: Evaluation & Development Board for a Power Management IC (PMIC)

• Likely IC Function: Multi-phase DC/DC controller or voltage regulator

• Features: May include adjustable outputs, current sensing, telemetry, and synchronization interfaces.

• Use Case: Enables validation of power supply designs before final PCB layout.

Applications:

• Prototyping power supplies for servers, GPUs, or ASICs

• Evaluating load transient performance and efficiency of ADI controllers

• University research in advanced power electronics

• Troubleshooting or replacing a similar board in existing test setups
