The Agilent Technologies E5850A Time Correlation Fixture automates and simplifies the tedious process of setting up an oscilloscope and a logic analyzer to cross-trigger and make time-correlated measurements. It measures skew between the two instruments and configures them for cross-triggering

The Agilent E5850A is comprised of a Time Correlation Fixture and software to automate the correlation tasks. The Agilent E5850A produces mixed displays of correlated logic analysis and oscilloscope waveforms and coordinates marker moves between the Logic Analysis System and the Infiniium 548XX.
