Accu-Glass Products In-Line Connector – BAG of 5

Key Specifications

• Model: ILC72-5 (In-Line Connector – 0.072″)

• Part Number: 110111

• Package: 5 pieces per package.

• Inner diameter (ID): 0.072 inches

• Outer diameter (OD): 0.187 inches

• Length / Height: 0.500 inches

• Materials: Beryllium Copper contact; gold-plated. Stainless steel screws.

• Operating / Bake temperature: Max bake temperature 400 °C; Max operating temperature 400 °C.

• Vacuum compatibility: Max vacuum level 1 × 10⁻¹⁰ Torr.

• Gender: Female contact.

• Wire acceptance: Designed to mate with feedthrough pins or conductors of comparable size. In-Line connectors in this series are non-insulated, gold-plated, Be-Cu contacts for air and/or in-vacuum, high-current service.

• Current rating: In-Line series available up to ~35 A when used with “.250 diameter OFE Copper feedthroughs”.
