Watec WAT-902H Monochrome Camera

Description

The Watec WAT-902H is a high-sensitivity monochrome CCTV camera designed for low-light surveillance applications. It utilizes a 1/2-inch interline transfer CCD image sensor, providing 570 TV lines of resolution.

Key Specifications:

• Effective Pixels: 380,000 (EIA), 440,000 (CCIR)


• Minimum Illumination: 0.0003 lux at F1.4


• Gain Control: Automatic Gain Control (AGC) with High (5–50 dB) and Low (5–32 dB) settings


• Back Light Compensation (BLC): Enabled


• Signal-to-Noise Ratio (S/N): 46 dB


• Shutter Speeds: Electronic Iris (EI) ranging from 1/60 (EIA) or 1/50 (CCIR) to 1/100,000 seconds
